Ford Transit Van Buyer's Guide (2026)
Last verified October 22, 2026 · Swant Graber Ford, Barron, WI
The 2026 Ford Transit is a full-size van sold as a Cargo Van, Passenger Van, Chassis Cab and Cutaway, with a 275-hp V6 or 300-hp EcoBoost and up to 6,900 lbs of towing. Swant Graber Ford in Barron, WI checked every figure against Ford's published specifications. New vehicles at Swant Graber Ford are sold at invoice with no dealer add-ons.
Shop Transit inventory at Swant Graber · new vehicles sold at invoice, no dealer add-ons · call 715-537-9500
New Transit in stockUsed TransitFord Blue Advantage certified TransitAll new FordAll used FordAbout Ford Blue Advantage certifiedEvery inventory link
| Quick fact | Answer |
|---|---|
| Body styles | Cargo Van, Passenger Van (XL/XLT, up to 15 seats), Chassis Cab, Cutaway |
| Engines | 3.5L PFDI V6, 275 hp / 260 lb-ft (standard); 3.5L EcoBoost V6, 300 hp / 400 lb-ft; 10-speed automatic |
| Drive | RWD standard; AWD available |
| Max towing | 6,900 lbs (Cargo Van, EcoBoost, 130" wheelbase, RWD) |
| Max payload | 5,103 lbs (T-350HD High Roof Extended DRW Cargo) |
| Roofs / lengths | Low, Medium, High; Regular, Long, Extended |
| Pricing at Swant Graber | New vehicles sold at invoice, no dealer add-ons; doc fee $127.50 |
Transit body styles and configurations
The 2026 Ford Transit is built as a Cargo Van (130- or 148-inch wheelbase), a Passenger Van with up to 15 seats, and a Chassis Cab or Cutaway (138-, 156- or 178-inch wheelbase) for upfits, with low, medium or high roofs.
| Cargo Van config | Cargo volume behind row 1 (cu ft) |
|---|---|
| Regular, Low roof | 246.7 |
| Long, Low roof | 277.7 |
| Long, Medium roof | 357.1 |
| Long, High roof | 404.3 |
| Extended, High roof | 487.3 |
Ford 2026 Transit Technical Specifications.
Transit engines, towing and payload
Every 2026 Transit uses a 10-speed automatic with either the 275-hp 3.5L PFDI V6 or the 300-hp, 400 lb-ft 3.5L EcoBoost; a properly equipped EcoBoost Cargo Van tows up to 6,900 lbs, and payload reaches 5,103 lbs on a T-350HD dual-rear-wheel cargo van.
| Model / engine | Max towing RWD / AWD (lbs) |
|---|---|
| Cargo Van 130", PFDI V6 (3.73/4.10) | 5,300/6,400 · 5,000/6,100 |
| Cargo Van 130", EcoBoost | 6,900 · 6,700 |
| Cargo Van 148", EcoBoost | 6,800 · 6,600 |
| Passenger Van 148", PFDI V6 | 4,200/4,500 · 4,000/4,300 |
| Passenger Van 148", EcoBoost | 4,400 · 4,200 |
Ford 2026 Transit Technical Specifications. Bumper-only towing max is 5,000 lbs.
2026 vs. 2027 Transit
As of October 22, 2026, Ford's published Transit specifications are for the 2026 model; we'll update this guide when Ford publishes the 2027 gas Transit.
Call Swant Graber Ford at 715-537-9500 for order timing and upfit planning.
Used Transit: what to check
On a used Transit, confirm the engine, the T-150/250/350 rating, roof height and wheelbase on the door-jamb label, because payload and towing vary widely by configuration.
Certified used Transit: how CPO changes the decision
Swant Graber Ford is a Ford Blue Advantage dealer: a Gold Certified Transit (up to 6 years old, under 80,000 miles) adds a 12-month/12,000-mile comprehensive limited warranty and a 7-year/100,000-mile powertrain limited warranty.
- Gold Certified: Ford models up to 6 years old and under 80,000 miles, 172-point inspection, 12-month/12,000-mile comprehensive limited warranty, 7-year/100,000-mile powertrain limited warranty.
- Blue Certified: vehicles up to 10 years old and under 150,000 miles, 139-point inspection, 90-day/4,000-mile comprehensive limited warranty.
- Swant Graber Ford participates in Ford Blue Advantage's 14-day/1,000-mile Money Back Guarantee; Ford's conditions apply.
- Non-certified used vehicles at Swant Graber include 45 days / 5,000 miles powertrain, on used units 10 model years or newer with under 150,000 miles. See dealer for details.
How it changes the decision: Gold Certified's 7-year/100,000-mile powertrain coverage is longer than the 5-year/60,000-mile powertrain warranty on a new Ford, so a 2–4-year-old Gold unit can be the value play if you don't need the newest changes. Ford Blue Advantage at Swant Graber Ford · Ford certified pre-owned · warranty guide
Also see: Transit recalls by year · CarBravo vs. Blue Advantage vs. Stellantis CPO. Check open recalls on any VIN at nhtsa.gov/recalls.
Owning a Transit in northwest Wisconsin
For northwest Wisconsin contractors and churches, an AWD Transit on winter tires is the confident winter pick, and the EcoBoost is the engine to choose for trailers over 4,500 lbs.
- AWD is available on Cargo and Passenger Vans.
- Both engines are E85 compatible per Ford.
- Plan a spring underbody wash after salt season.
Local guides: Towing an ice house and driving on lake ice · 4WD modes in winter · Winter vehicle prep · Snowmobile trailer towing in Wisconsin · Winter prep and block heater service.
Shop Transit inventory at Swant Graber · new vehicles sold at invoice, no dealer add-ons · call 715-537-9500
New Transit in stockUsed TransitFord Blue Advantage certified TransitAll new FordAll used FordAbout Ford Blue Advantage certifiedEvery inventory link
Frequently asked questions
How much can a Ford Transit tow?
Up to 6,900 lbs (EcoBoost Cargo Van, 130" wheelbase, RWD).
What engines does the 2026 Transit have?
A 275-hp 3.5L PFDI V6 or a 300-hp 3.5L EcoBoost V6.
Is the Transit available with AWD?
Yes, AWD is available.
How many people does a Transit Passenger Van seat?
Up to 15.
Where can I buy a Transit near Rice Lake?
Swant Graber Ford, 1697 E Division Ave, Barron, WI. Call 715-537-9500.
How does Swant Graber price a new Ford Transit?
Swant Graber Ford in Barron, WI sells new vehicles at invoice with no dealer add-ons. Taxes, title, registration and the $127.50 doc fee are extra.
Sources and verification
Last verified October 22, 2026 by Swant Graber Auto Group against these manufacturer and government sources. Features, ratings and availability can change; the window sticker and door-jamb labels on the exact vehicle govern.
- Ford Media: 2026 Ford Transit Technical Specifications (PDF) (engines, towing)
- Ford.com: 2026 Ford Transit Passenger Van (retrieved Oct 22, 2026; payload FAQ)
- Ford Blue Advantage program (Ford) (Gold and Blue Certified terms, retrieved Oct 2026)
- NHTSA recall lookup by VIN
